FAG 16036 Bearing

FAG 16036 bearings

Also known as : 16036

  • Inside Diameter: 180 mm
  • Outside Diameter: 280 mm
  • Width: 31 mm
  • Basic dynamic load rating: 140 kN
  • Basic static load rating: 146 kN

Inquire Now


FAG 16036 Bearing

FAG 16036 Bearing details

d 180 mm
D 280 mm
B 31 mm
D1 238,8 mm
Da max 271,2 mm
d1 211,9 mm
da min 188,8 mm
ra max 2 mm
rmin 2 mm
m 6,92 kg  Mass
Cr 140000 N  Basic dynamic load rating, radial
C0r 146000 N  Basic static load rating, radial
Cur 5200 N  Fatigue limit load, radial
nG 3350 1/min  Limiting speed
nB 2950 1/min  Reference speed
f0 16,4  Calculation factor

As FAG bearing distributor, Nodes bearings have FAG 16036 deep groove ball bearings in stock, main dimensions to DIN 625-1.

FAG 16036 bearing cross reference

NSK 16036 bearing
180mm x 280mm x 31mm
NSK 16036 bearing
180mm x 280mm x 31mm
SKF 16036 bearing
180mm x 280mm x 31mm
FAG 6036-M bearing
180mm x 280mm x 46mm
FAG 6036-M-J20AA bearing
180mm x 280mm x 46mm
FAG 61836 bearing
180mm x 225mm x 22mm
FAG 61836-MB bearing
180mm x 225mm x 22mm
FAG 61936 bearing
180mm x 250mm x 33mm
FAG 61936-MA bearing
180mm x 250mm x 33mm
FAG 6236-M-C3 bearing
180mm x 320mm x 52mm
FAG 6236-M-J20AA bearing
180mm x 320mm x 52mm
FAG 6236-M-J20C bearing
180mm x 320mm x 52mm
