FAG ball bearings come in a wide variety of types, designs, series, sizes, variants and materials. As a FAG Bearing distributor, Nodes bearings have FAG deep groove ball bearing, angular contact ball bearing, self-aligning ball bearing, super precision ball bearing in our stock.
FAG bearings are the biggest selling brands in our company with a wide range of types. As FAG bearings distributor, we offer: On time deliveries, no minimums quantities, and combined sales experience of over 20 years in this field
FAG 3804-B-2RS-TVH bearings | Dimensions: 20x32x10mm
Nodes bearings have FAG 3804-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3804-B-2RS-TVH bearings dimensions: 20mm x 32mm x 10mm, Cr: 5600N, C0r: 4750N.
- Brand: FAG
- Inside Diameter: 20 mm
- Outside Diameter: 32 mm
- Width: 10 mm
- Basic dynamic load rating: 5.6 kN
- Basic static load rating: 5.6 kN
FAG 3805-B-2RS-TVH bearings | Dimensions: 25x37x10mm
Nodes bearings have FAG 3805-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3805-B-2RS-TVH bearings dimensions: 25mm x 37mm x 10mm, Cr: 5900N, C0r: 5500N.
- Brand: FAG
- Inside Diameter: 25 mm
- Outside Diameter: 37 mm
- Width: 10 mm
- Basic dynamic load rating: 5.9 kN
- Basic static load rating: 5.9 kN
FAG 3807-B-2RS-TVH bearings | Dimensions: 35x47x10mm
Nodes bearings have FAG 3807-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3807-B-2RS-TVH bearings dimensions: 35mm x 47mm x 10mm, Cr: 6500N, C0r: 6800N.
- Brand: FAG
- Inside Diameter: 35 mm
- Outside Diameter: 47 mm
- Width: 10 mm
- Basic dynamic load rating: 6.5 kN
- Basic static load rating: 6.5 kN
FAG 3808-B-2RS-TVH bearings | Dimensions: 40x52x10mm
Nodes bearings have FAG 3808-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3808-B-2RS-TVH bearings dimensions: 40mm x 52mm x 10mm, Cr: 6900N, C0r: 7600N.
- Brand: FAG
- Inside Diameter: 40 mm
- Outside Diameter: 52 mm
- Width: 10 mm
- Basic dynamic load rating: 6.9 kN
- Basic static load rating: 6.9 kN
FAG 3809-B-2RS-TVH bearings | Dimensions: 45x58x10mm
Nodes bearings have FAG 3809-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3809-B-2RS-TVH bearings dimensions: 45mm x 58mm x 10mm, Cr: 7000N, C0r: 8100N.
- Brand: FAG
- Inside Diameter: 45 mm
- Outside Diameter: 58 mm
- Width: 10 mm
- Basic dynamic load rating: 7 kN
- Basic static load rating: 7 kN
FAG 3202-BD-XL-TVH bearings | Dimensions: 15x35x15.9mm
Nodes bearings have FAG 3202-BD-XL-TVH bearings in stock, Angular contact ball bearings, 3202-BD-XL-TVH bearings dimensions: 15mm x 35mm x 15.9mm, Cr: 12600N, C0r: 7400N.
- Brand: FAG
- Inside Diameter: 15 mm
- Outside Diameter: 35 mm
- Width: 15.9 mm
- Basic dynamic load rating: 12.6 kN
- Basic static load rating: 12.6 kN
FAG 3203-BD-XL-TVH bearings | Dimensions: 17x40x17.5mm
Nodes bearings have FAG 3203-BD-XL-TVH bearings in stock, Angular contact ball bearings, 3203-BD-XL-TVH bearings dimensions: 17mm x 40mm x 17.5mm, Cr: 15500N, C0r: 9500N.
- Brand: FAG
- Inside Diameter: 17 mm
- Outside Diameter: 40 mm
- Width: 17.5 mm
- Basic dynamic load rating: 15.5 kN
- Basic static load rating: 15.5 kN
FAG 3204-BD-XL-TVH bearings | Dimensions: 20x47x20.6mm
Nodes bearings have FAG 3204-BD-XL-TVH bearings in stock, Angular contact ball bearings, 3204-BD-XL-TVH bearings dimensions: 20mm x 47mm x 20.6mm, Cr: 20600N, C0r: 12900N.
- Brand: FAG
- Inside Diameter: 20 mm
- Outside Diameter: 47 mm
- Width: 20.6 mm
- Basic dynamic load rating: 20.6 kN
- Basic static load rating: 20.6 kN
FAG 3205-BD-XL bearings | Dimensions: 25x52x20.6mm
Nodes bearings have FAG 3205-BD-XL bearings in stock, Angular contact ball bearings, 3205-BD-XL bearings dimensions: 25mm x 52mm x 20.6mm, Cr: 22000N, C0r: 15200N.
- Brand: FAG
- Inside Diameter: 25 mm
- Outside Diameter: 52 mm
- Width: 20.6 mm
- Basic dynamic load rating: 22 kN
- Basic static load rating: 22 kN
FAG 7005-B-XL-2RS-TVP bearings | Dimensions: 25x47x12mm
Nodes bearings have FAG 7005-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, contact angle α = 40°, lip seals on both sides, 7005-B-XL-2RS-TVP bearings dimensions: 25mm x 47mm x 12mm, Cr: 16000N, C0r: 9900N.
- Brand: FAG
- Inside Diameter: 25 mm
- Outside Diameter: 47 mm
- Width: 12 mm
- Basic dynamic load rating: 16 kN
- Basic static load rating: 16 kN
FAG 7006-B-XL-2RS-TVP bearings | Dimensions: 30x55x13mm
Nodes bearings have FAG 7006-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, contact angle α = 40°, lip seals on both sides, 7006-B-XL-2RS-TVP bearings dimensions: 30mm x 55mm x 13mm, Cr: 19900N, C0r: 13400N.
- Brand: FAG
- Inside Diameter: 30 mm
- Outside Diameter: 55 mm
- Width: 13 mm
- Basic dynamic load rating: 19.9 kN
- Basic static load rating: 19.9 kN
FAG 7007-B-XL-2RS-TVP bearings | Dimensions: 35x62x14mm
Nodes bearings have FAG 7007-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, contact angle α = 40°, lip seals on both sides, 7007-B-XL-2RS-TVP bearings dimensions: 35mm x 62mm x 14mm, Cr: 24300N, C0r: 17200N.
- Brand: FAG
- Inside Diameter: 35 mm
- Outside Diameter: 62 mm
- Width: 14 mm
- Basic dynamic load rating: 24.3 kN
- Basic static load rating: 24.3 kN
FAG 3810-B-2RS-TVH bearings | Dimensions: 50x65x12mm
Nodes bearings have FAG 3810-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3810-B-2RS-TVH bearings dimensions: 50mm x 65mm x 12mm, Cr: 8500N, C0r: 10200N.
- Brand: FAG
- Inside Diameter: 50 mm
- Outside Diameter: 65 mm
- Width: 12 mm
- Basic dynamic load rating: 8.5 kN
- Basic static load rating: 8.5 kN
FAG 3811-B-2RS-TVH bearings | Dimensions: 55x72x13mm
Nodes bearings have FAG 3811-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3811-B-2RS-TVH bearings dimensions: 55mm x 72mm x 13mm, Cr: 10700N, C0r: 13100N.
- Brand: FAG
- Inside Diameter: 55 mm
- Outside Diameter: 72 mm
- Width: 13 mm
- Basic dynamic load rating: 10.7 kN
- Basic static load rating: 10.7 kN
FAG 3812-B-2RS-TVH bearings | Dimensions: 60x78x14mm
Nodes bearings have FAG 3812-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3812-B-2RS-TVH bearings dimensions: 60mm x 78mm x 14mm, Cr: 14200N, C0r: 17100N.
- Brand: FAG
- Inside Diameter: 60 mm
- Outside Diameter: 78 mm
- Width: 14 mm
- Basic dynamic load rating: 14.2 kN
- Basic static load rating: 14.2 kN
FAG 3814-B-2RS-TVH bearings | Dimensions: 70x90x15mm
Nodes bearings have FAG 3814-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3814-B-2RS-TVH bearings dimensions: 70mm x 90mm x 15mm, Cr: 18800N, C0r: 23200N.
- Brand: FAG
- Inside Diameter: 70 mm
- Outside Diameter: 90 mm
- Width: 15 mm
- Basic dynamic load rating: 18.8 kN
- Basic static load rating: 18.8 kN
FAG 3816-B-2RS-TVH bearings | Dimensions: 80x100x15mm
Nodes bearings have FAG 3816-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3816-B-2RS-TVH bearings dimensions: 80mm x 100mm x 15mm, Cr: 19200N, C0r: 24800N.
- Brand: FAG
- Inside Diameter: 80 mm
- Outside Diameter: 100 mm
- Width: 15 mm
- Basic dynamic load rating: 19.2 kN
- Basic static load rating: 19.2 kN
FAG 3208-BD-XL bearings | Dimensions: 40x80x30.2mm
Nodes bearings have FAG 3208-BD-XL bearings in stock, Angular contact ball bearings, 3208-BD-XL bearings dimensions: 40mm x 80mm x 30.2mm, Cr: 51000N, C0r: 38000N.
- Brand: FAG
- Inside Diameter: 40 mm
- Outside Diameter: 80 mm
- Width: 30.2 mm
- Basic dynamic load rating: 51 kN
- Basic static load rating: 51 kN
FAG 3209-BD-XL bearings | Dimensions: 45x85x30.2mm
Nodes bearings have FAG 3209-BD-XL bearings in stock, Angular contact ball bearings, 3209-BD-XL bearings dimensions: 45mm x 85mm x 30.2mm, Cr: 50000N, C0r: 39000N.
- Brand: FAG
- Inside Diameter: 45 mm
- Outside Diameter: 85 mm
- Width: 30.2 mm
- Basic dynamic load rating: 50 kN
- Basic static load rating: 50 kN
FAG 3209-BD-XL-TVH bearings | Dimensions: 45x85x30.2mm
Nodes bearings have FAG 3209-BD-XL-TVH bearings in stock, Angular contact ball bearings, 3209-BD-XL-TVH bearings dimensions: 45mm x 85mm x 30.2mm, Cr: 50000N, C0r: 39000N.
- Brand: FAG
- Inside Diameter: 45 mm
- Outside Diameter: 85 mm
- Width: 30.2 mm
- Basic dynamic load rating: 50 kN
- Basic static load rating: 50 kN
FAG 3210-BD-XL bearings | Dimensions: 50x90x30.2mm
Nodes bearings have FAG 3210-BD-XL bearings in stock, Angular contact ball bearings, 3210-BD-XL bearings dimensions: 50mm x 90mm x 30.2mm, Cr: 53000N, C0r: 44000N.
- Brand: FAG
- Inside Diameter: 50 mm
- Outside Diameter: 90 mm
- Width: 30.2 mm
- Basic dynamic load rating: 53 kN
- Basic static load rating: 53 kN
FAG 3818-B-2RS-TVH bearings | Dimensions: 90x115x19mm
Nodes bearings have FAG 3818-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3818-B-2RS-TVH bearings dimensions: 90mm x 115mm x 19mm, Cr: 27000N, C0r: 35500N.
- Brand: FAG
- Inside Diameter: 90 mm
- Outside Diameter: 115 mm
- Width: 19 mm
- Basic dynamic load rating: 27 kN
- Basic static load rating: 27 kN
FAG 3820-B-2RS-TVH bearings | Dimensions: 100x125x19mm
Nodes bearings have FAG 3820-B-2RS-TVH bearings in stock, Angular contact ball bearings, 3820-B-2RS-TVH bearings dimensions: 100mm x 125mm x 19mm, Cr: 28000N, C0r: 39000N.
- Brand: FAG
- Inside Diameter: 100 mm
- Outside Diameter: 125 mm
- Width: 19 mm
- Basic dynamic load rating: 28 kN
- Basic static load rating: 28 kN
FAG 30/6-B-2Z-TVH bearings | Dimensions: 6x17x9mm
Nodes bearings have FAG 30/6-B-2Z-TVH bearings in stock, Angular contact ball bearings, 30/6-B-2Z-TVH bearings dimensions: 6mm x 17mm x 9mm, Cr: 3050N, C0r: 1400N.
- Brand: FAG
- Inside Diameter: 6 mm
- Outside Diameter: 17 mm
- Width: 9 mm
- Basic dynamic load rating: 3.05 kN
- Basic static load rating: 3.05 kN
FAG 30/7-B-2Z-TVH bearings | Dimensions: 7x19x10mm
Nodes bearings have FAG 30/7-B-2Z-TVH bearings in stock, Angular contact ball bearings, 30/7-B-2Z-TVH bearings dimensions: 7mm x 19mm x 10mm, Cr: 3650N, C0r: 1690N.
- Brand: FAG
- Inside Diameter: 7 mm
- Outside Diameter: 19 mm
- Width: 10 mm
- Basic dynamic load rating: 3.65 kN
- Basic static load rating: 3.65 kN
FAG 30/8-B-2Z-TVH bearings | Dimensions: 8x22x11mm
Nodes bearings have FAG 30/8-B-2Z-TVH bearings in stock, Angular contact ball bearings, 30/8-B-2Z-TVH bearings dimensions: 8mm x 22mm x 11mm, Cr: 5100N, C0r: 2600N.
- Brand: FAG
- Inside Diameter: 8 mm
- Outside Diameter: 22 mm
- Width: 11 mm
- Basic dynamic load rating: 5.1 kN
- Basic static load rating: 5.1 kN
FAG 3211-BD-XL-TVH bearings | Dimensions: 55x100x33.3mm
Nodes bearings have FAG 3211-BD-XL-TVH bearings in stock, Angular contact ball bearings, 3211-BD-XL-TVH bearings dimensions: 55mm x 100mm x 33.3mm, Cr: 61000N, C0r: 51000N.
- Brand: FAG
- Inside Diameter: 55 mm
- Outside Diameter: 100 mm
- Width: 33.3 mm
- Basic dynamic load rating: 61 kN
- Basic static load rating: 61 kN
FAG 3213-BD-XL-TVH bearings | Dimensions: 65x120x38.1mm
Nodes bearings have FAG 3213-BD-XL-TVH bearings in stock, Angular contact ball bearings, 3213-BD-XL-TVH bearings dimensions: 65mm x 120mm x 38.1mm, Cr: 86000N, C0r: 77000N.
- Brand: FAG
- Inside Diameter: 65 mm
- Outside Diameter: 120 mm
- Width: 38.1 mm
- Basic dynamic load rating: 86 kN
- Basic static load rating: 86 kN
FAG 3302-BD-XL-TVH bearings | Dimensions: 15x42x19mm
Nodes bearings have FAG 3302-BD-XL-TVH bearings in stock, Angular contact ball bearings, 3302-BD-XL-TVH bearings dimensions: 15mm x 42mm x 19mm, Cr: 17000N, C0r: 10400N.
- Brand: FAG
- Inside Diameter: 15 mm
- Outside Diameter: 42 mm
- Width: 19 mm
- Basic dynamic load rating: 17 kN
- Basic static load rating: 17 kN
FAG 3303-BD-XL-TVH bearings | Dimensions: 17x47x22.2mm
Nodes bearings have FAG 3303-BD-XL-TVH bearings in stock, Angular contact ball bearings, 3303-BD-XL-TVH bearings dimensions: 17mm x 47mm x 22.2mm, Cr: 22500N, C0r: 13100N.
- Brand: FAG
- Inside Diameter: 17 mm
- Outside Diameter: 47 mm
- Width: 22.2 mm
- Basic dynamic load rating: 22.5 kN
- Basic static load rating: 22.5 kN
FAG 7200-B-XL-2RS-TVP bearings | Dimensions: 10x30x9mm
Nodes bearings have FAG 7200-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, main dimensions to DIN 628-1, contact angle α = 40°, lip seals on both sides, 7200-B-XL-2RS-TVP bearings dimensions: 10mm x 30mm x 9mm, Cr: 5300N, C0r
- Brand: FAG
- Inside Diameter: 10 mm
- Outside Diameter: 30 mm
- Width: 9 mm
- Basic dynamic load rating: 5.3 kN
- Basic static load rating: 5.3 kN
FAG 7202-B-XL-2RS-TVP bearings | Dimensions: 15x35x11mm
Nodes bearings have FAG 7202-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, main dimensions to DIN 628-1, contact angle α = 40°, lip seals on both sides, 7202-B-XL-2RS-TVP bearings dimensions: 15mm x 35mm x 11mm, Cr: 8400N, C0
- Brand: FAG
- Inside Diameter: 15 mm
- Outside Diameter: 35 mm
- Width: 11 mm
- Basic dynamic load rating: 8.4 kN
- Basic static load rating: 8.4 kN
FAG 7203-B-XL-2RS-TVP bearings | Dimensions: 17x40x12mm
Nodes bearings have FAG 7203-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, main dimensions to DIN 628-1, contact angle α = 40°, lip seals on both sides, 7203-B-XL-2RS-TVP bearings dimensions: 17mm x 40mm x 12mm, Cr: 10500N, C
- Brand: FAG
- Inside Diameter: 17 mm
- Outside Diameter: 40 mm
- Width: 12 mm
- Basic dynamic load rating: 10.5 kN
- Basic static load rating: 10.5 kN
FAG 7204-B-XL-2RS-TVP bearings | Dimensions: 20x47x14mm
Nodes bearings have FAG 7204-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, main dimensions to DIN 628-1, contact angle α = 40°, lip seals on both sides, 7204-B-XL-2RS-TVP bearings dimensions: 20mm x 47mm x 14mm, Cr: 14000N, C
- Brand: FAG
- Inside Diameter: 20 mm
- Outside Diameter: 47 mm
- Width: 14 mm
- Basic dynamic load rating: 14 kN
- Basic static load rating: 14 kN
FAG 7205-B-XL-2RS-TVP bearings | Dimensions: 25x52x15mm
Nodes bearings have FAG 7205-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, main dimensions to DIN 628-1, contact angle α = 40°, lip seals on both sides, 7205-B-XL-2RS-TVP bearings dimensions: 25mm x 52mm x 15mm, Cr: 15300N, C
- Brand: FAG
- Inside Diameter: 25 mm
- Outside Diameter: 52 mm
- Width: 15 mm
- Basic dynamic load rating: 15.3 kN
- Basic static load rating: 15.3 kN
FAG 7206-B-XL-2RS-TVP bearings | Dimensions: 30x62x16mm
Nodes bearings have FAG 7206-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, main dimensions to DIN 628-1, contact angle α = 40°, lip seals on both sides, 7206-B-XL-2RS-TVP bearings dimensions: 30mm x 62mm x 16mm, Cr: 21700N, C
- Brand: FAG
- Inside Diameter: 30 mm
- Outside Diameter: 62 mm
- Width: 16 mm
- Basic dynamic load rating: 21.7 kN
- Basic static load rating: 21.7 kN
FAG 7207-B-XL-2RS-TVP bearings | Dimensions: 35x72x17mm
Nodes bearings have FAG 7207-B-XL-2RS-TVP bearings in stock, Angular contact ball bearings, main dimensions to DIN 628-1, contact angle α = 40°, lip seals on both sides, 7207-B-XL-2RS-TVP bearings dimensions: 35mm x 72mm x 17mm, Cr: 28000N, C
- Brand: FAG
- Inside Diameter: 35 mm
- Outside Diameter: 72 mm
- Width: 17 mm
- Basic dynamic load rating: 28 kN
- Basic static load rating: 28 kN
FAG 3200-B-2Z-TVH bearings | Dimensions: 10x30x14mm
Nodes bearings have FAG 3200-B-2Z-TVH bearings in stock, Angular contact ball bearings, 3200-B-2Z-TVH bearings dimensions: 10mm x 30mm x 14mm, Cr: 7800N, C0r: 4450N.
- Brand: FAG
- Inside Diameter: 10 mm
- Outside Diameter: 30 mm
- Width: 14 mm
- Basic dynamic load rating: 7.8 kN
- Basic static load rating: 7.8 kN
