FAG QJ318-N2-MPA Bearing

FAG QJ318-N2-MPA bearings | Dimensions: 90x190x43mm

Also known as : QJ318-N2-MPA

• Inside Diameter: 90 mm
• Outside Diameter: 190 mm
• Width: 43 mm
• Basic dynamic load rating: 265 kN
• Basic static load rating: 285 kN

Inquire Now

FAG QJ318-N2-MPA Bearing

Number	QJ318-N2-MPA
Type	Four point contact bearings main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots
d	90mm
D	190mm
B	43mm
	45°	Groove angle
a	98mm
an	11,7mm
bn	10,5mm
D1	157,1mm
Da max	176mm
d1	124,5mm
da min	104mm
ra max	2,5mm
rmin	3mm
rn	2mm
α	35°	Contact angle
m	6,31kg	Mass
Cr	265000N	Basic dynamic load rating, radial
C0r	285000N	Basic static load rating, radial
Cur	13300N	Fatigue limit load, radial
nG	63001/min	Limiting speed
nϑr	33501/min	Reference speed

Nodes bearings have FAG QJ318-N2-MPA bearings in stock, FAG bearings, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots.
