FAG QJ320-N2-MPA Bearing

FAG QJ320-N2-MPA bearings | Dimensions: 100x215x47mm

Also known as : QJ320-N2-MPA

• Inside Diameter: 100 mm
• Outside Diameter: 215 mm
• Width: 47 mm
• Basic dynamic load rating: 325 kN
• Basic static load rating: 365 kN

Inquire Now

FAG QJ320-N2-MPA Bearing

Number	QJ320-N2-MPA
Type	Four point contact bearings main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots
d	100mm
D	215mm
B	47mm
	45°	Groove angle
a	110mm
an	11,7mm
bn	10,5mm
D1	176,6mm
Da max	201mm
d1	139mm
da min	114mm
ra max	2,5mm
rmin	3mm
rn	2mm
α	35°	Contact angle
m	9,04kg	Mass
Cr	325000N	Basic dynamic load rating, radial
C0r	365000N	Basic static load rating, radial
Cur	16800N	Fatigue limit load, radial
nG	54001/min	Limiting speed
nϑr	30001/min	Reference speed

Nodes bearings have FAG QJ320-N2-MPA bearings in stock, FAG bearings, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots.
