FAG 23218-E1A-XL-M Spherical roller bearings
Also known as : 23218CAM/W33, 23218CAE4
- Inside Diameter: 90 mm
- Outside Diameter: 160 mm
- Width: 52.4 mm
- Basic dynamic load rating: 445 kN
- Basic static load rating: 520 kN
FAG 23218-E1A-XL-M Bearing
FAG 23218-E1A-XL-M Bearing details
model | 23218-E1A-XL-M |
---|---|
d | 90 mm |
D | 160 mm |
B | 52.4 mm |
D1 | 140 mm |
Da max | 149 mm |
da min | 101 mm |
ds | 3.2 mm |
ns | 6.5 mm |
ra max | 2 mm |
rmin | 2 mm |
Cr | 445000 N |
C0r | 520000 N |
Limiting speed | 4250 1/min |
Reference speed | 2650 1/min |
Cur | 48500 N Fatigue limit load, radial |
e | 0.31 |
Y1 | 2.2 |
Y2 | 3.27 |
Y0 | 2.15 |
mass | 4.5 kg |
FAG 23218-E1A-XL-M roller bearings, spherical roller bearing, main dimensions to DIN 635-2.
