FAG 30214-XL tapered roller bearings
Also known as : 30214-XL,
- Inside Diameter: 70 mm
- Outside Diameter: 125 mm
- Width: 26.25 mm
- Basic dynamic load rating: 155 kN
- Basic static load rating: 162 kN
FAG 30214-XL Bearing
FAG 30214-XL Bearing details
model | 30214-XL |
---|---|
d | 70 mm |
D | 125 mm |
T | 26.25 mm |
a | 25 mm |
B | 24 mm |
C | 21 mm |
Ca min | 4 mm |
Cb min | 5 mm |
Da max | 116 mm |
Da min | 110 mm |
Db min | 118 mm |
d1 | 95.2 mm |
da max | 81 mm |
db min | 79 mm |
r1,2 min | 2 mm |
r3,4 min | 1.5 mm |
ra max | 2 mm |
rb max | 1.5 mm |
Cr | 155000 N, Basic dynamic load rating, radial |
C0r | 162000 N, Basic static load rating, radial |
Limiting speed | 5800 1/min |
Reference speed | 3700 1/min |
Cur | 24500 N, Fatigue limit load, radial |
e | 0.42 |
Y | 1.43 |
Y0 | 0.79 |
mass | 1.31 kg |
Nodes bearings have FAG 30214-XL roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
