FAG 30218-A tapered roller bearings
Also known as : 30218-A,
- Inside Diameter: 90 mm
- Outside Diameter: 160 mm
- Width: 32.5 mm
- Basic dynamic load rating: 201 kN
- Basic static load rating: 255 kN
FAG 30218-A Bearing
FAG 30218-A Bearing details
model | 30218-A |
---|---|
d | 90 mm |
D | 160 mm |
T | 32.5 mm |
a | 32 mm |
B | 30 mm |
C | 26 mm |
Ca min | 5 mm |
Cb min | 6.5 mm |
Da max | 150 mm |
Da min | 140 mm |
Db min | 150 mm |
d1 | 121.3 mm |
da max | 103 mm |
db min | 100 mm |
r1,2 min | 2.5 mm |
r3,4 min | 2 mm |
ra max | 2.5 mm |
rb max | 2 mm |
Cr | 201000 N, Basic dynamic load rating, radial |
C0r | 255000 N, Basic static load rating, radial |
Limiting speed | 4550 1/min |
Reference speed | 3100 1/min |
Cur | 29000 N, Fatigue limit load, radial |
e | 0.42 |
Y | 1.43 |
Y0 | 0.79 |
mass | 2.64 kg |
Nodes bearings have FAG 30218-A roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
