FAG 30234-XL-DF-A280-330 tapered roller bearings
Also known as : 30234-XL-DF-A280-330,
- Inside Diameter: 170 mm
- Outside Diameter: 310 mm
- Width: 114 mm
- Basic dynamic load rating: 1190 kN
- Basic static load rating: 1620 kN
FAG 30234-XL-DF-A280-330 Bearing
FAG 30234-XL-DF-A280-330 Bearing details
| model | 30234-XL-DF-A280-330 |
|---|---|
| d | 170 mm |
| D | 310 mm |
| 2T | 114 mm |
| 2B | 104 mm |
| A | 28 mm |
| Ca min | 8 mm |
| Da max | 292 mm |
| Da min | 269 mm |
| da max | 203 mm |
| r3,4 min | 4 mm |
| rb max | 4 mm |
| Cr | 1190000 N, Basic dynamic load rating, radial |
| C0r | 1620000 N, Basic static load rating, radial |
| Limiting speed | 2280 1/min |
| Reference speed | 1320 1/min |
| Cur | 202000 N, Fatigue limit load, radial |
| e | 0.43 |
| Y0 | 1.52 |
| Y1 | 1.55 |
| Y2 | 2.31 |
| mass | 35.4 kg |
Nodes bearings have FAG 30234-XL-DF-A280-330 roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, for fitting in pairs in X arrangement, with axial internal clearance.
