FAG 32007-X-XL Bearing

FAG 32007-X-XL tapered roller bearings

Also known as : 32007-X-XL, T4CC035,

• Inside Diameter: 35 mm
• Outside Diameter: 62 mm
• Width: 18 mm
• Basic dynamic load rating: 54 kN
• Basic static load rating: 57 kN

Inquire Now

FAG 32007-X-XL Bearing

model	32007-X-XL
Comparative designation to DIN ISO 355	T4CC035
d	35 mm
D	62 mm
T	18 mm
a	15 mm
B	18 mm
C	14 mm
Ca min	4 mm
Cb min	4 mm
Da max	56 mm
Da min	54 mm
Db min	59 mm
d1	50.1 mm
da max	40 mm
db min	41 mm
r1,2 min	1 mm
r3,4 min	1 mm
ra max	1 mm
rb max	1 mm
Cr	54000 N, Basic dynamic load rating, radial
C0r	57000 N, Basic static load rating, radial
Limiting speed	11600 1/min
Reference speed	7000 1/min
Cur	8900 N, Fatigue limit load, radial
e	0.45
Y	1.32
Y0	0.73
mass	0.225 kg

Nodes bearings have FAG 32007-X-XL roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
