FAG 32022-X-XL tapered roller bearings
Also known as : 32022-X-XL, T4DC110,
- Inside Diameter: 110 mm
- Outside Diameter: 170 mm
- Width: 38 mm
- Basic dynamic load rating: 285 kN
- Basic static load rating: 395 kN
FAG 32022-X-XL Bearing
FAG 32022-X-XL Bearing details
model | 32022-X-XL |
---|---|
Comparative designation to DIN ISO 355 |
T4DC110 |
d | 110 mm |
D | 170 mm |
T | 38 mm |
a | 37 mm |
B | 38 mm |
C | 29 mm |
Ca min | 7 mm |
Cb min | 9 mm |
Da max | 160 mm |
Da min | 152 mm |
Db min | 163 mm |
d1 | 141.2 mm |
da max | 122 mm |
db min | 120 mm |
r1,2 min | 2.5 mm |
r3,4 min | 2 mm |
ra max | 2.5 mm |
rb max | 2 mm |
Cr | 285000 N, Basic dynamic load rating, radial |
C0r | 395000 N, Basic static load rating, radial |
Limiting speed | 3950 1/min |
Reference speed | 2650 1/min |
Cur | 59000 N, Fatigue limit load, radial |
e | 0.43 |
Y | 1.39 |
Y0 | 0.77 |
mass | 3.06 kg |
Nodes bearings have FAG 32022-X-XL roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
