FAG N215-E-XL-TVP2 Cylindrical roller bearings
Also known as : N215-E-XL-TVP2, N215ECP, N215W
- Inside Diameter: 75 mm
- Outside Diameter: 130 mm
- Width: 25 mm
- Basic dynamic load rating: 155 kN
- Basic static load rating: 157 kN
FAG N215-E-XL-TVP2 Bearing
FAG N215-E-XL-TVP2 Bearing details
| model | N215-E-XL-TVP2 |
|---|---|
| d | 75 mm |
| D | 130 mm |
| B | 25 mm |
| Da max | 121 mm |
| Db min | 120 mm |
| Dc max | 117 mm |
| d1 | 94.4 mm |
| da min | 84 mm |
| E | 118.5 mm |
| F | 88.5 mm |
| r1 min | 1.5 mm |
| ra max | 1.5 mm |
| ra1 max | 1.5 mm |
| rmin | 1.5 mm |
| s | 1.1 mm, Axial displacement facility from central position |
| Cr | 155000 N, Basic dynamic load rating, radial |
| C0r | 157000 N, Basic static load rating, radial |
| Limiting speed | 6500 1/min |
| Reference speed | 4400 1/min |
| Cur | 27500 N, Fatigue limit load, radial |
| mass | 1.29 kg |
FAG N215-E-XL-TVP2 roller bearings, cylindrical roller bearings, non-locating bearing, separable, with cage.
FAG N215-E-XL-TVP2 bearing cross reference
FAG N315-E-XL-TVP2 bearing
75mm x 160mm x 37mm
FAG NJ215-E-XL-TVP2 bearing
75mm x 130mm x 25mm
FAG NJ315-E-XL-TVP2 bearing
75mm x 160mm x 37mm
FAG NJ2215-E-XL-TVP2 bearing
75mm x 130mm x 31mm
FAG NJ2315-E-XL-TVP2 bearing
75mm x 160mm x 55mm
FAG NJ415-XL-M1 bearing
75mm x 190mm x 45mm
FAG NU1015-XL-M1 bearing
75mm x 115mm x 20mm
FAG NU215-E-XL-TVP2 bearing
75mm x 130mm x 25mm
FAG NU315-E-XL-TVP2 bearing
75mm x 160mm x 37mm
FAG NU2215-E-XL-TVP2 bearing
75mm x 130mm x 31mm
FAG NU2315-E-XL-TVP2 bearing
75mm x 160mm x 55mm
