FAG NU2236-E-XL-M1 Cylindrical roller bearings
Also known as : NU2236-E-XL-M1, NU2236ECM
- Inside Diameter: 180 mm
- Outside Diameter: 320 mm
- Width: 86 mm
- Basic dynamic load rating: 1180 kN
- Basic static load rating: 1490 kN
FAG NU2236-E-XL-M1 Bearing
FAG NU2236-E-XL-M1 Bearing details
| model | NU2236-E-XL-M1 |
|---|---|
| d | 180 mm |
| D | 320 mm |
| B | 86 mm |
| D1 | 280 mm |
| Da max | 303 mm |
| da max | 214 mm |
| da min | 197 mm |
| db min | 221 mm |
| E | 291 mm |
| F | 215 mm |
| r1 min | 4 mm |
| ra max | 3 mm |
| ra1 max | 3 mm |
| rmin | 4 mm |
| s | 7.2 mm, Axial displacement facility from central position |
| Cr | 1180000 N, Basic dynamic load rating, radial |
| C0r | 1490000 N, Basic static load rating, radial |
| Limiting speed | 3200 1/min |
| Reference speed | 1380 1/min |
| Cur | 226000 N, Fatigue limit load, radial |
| mass | 30.7 kg |
FAG NU2236-E-XL-M1 roller bearings, cylindrical roller bearings, non-locating bearing, separable, with cage.
