FAG T7FC085-XL tapered roller bearings
Also known as : T7FC085
- Inside Diameter: 85 mm
- Outside Diameter: 170 mm
- Width: 48 mm
- Basic dynamic load rating: 310 kN
- Basic static load rating: 365 kN
FAG T7FC085-XL Bearing
FAG T7FC085-XL Bearing details
model | T7FC085-XL |
---|---|
d | 85 mm |
D | 170 mm |
T | 48 mm |
a | 55 mm |
B | 45 mm |
C | 33 mm |
Ca min | 7 mm |
Cb min | 15 mm |
Da max | 153 mm |
Da min | 131 mm |
Db min | 161 mm |
d1 | 132 mm |
da max | 100 mm |
db min | 110 mm |
r1,2 min | 4 mm |
r3,4 min | 4 mm |
ra max | 4 mm |
rb max | 4 mm |
Cr | 310000 N, Basic dynamic load rating, radial |
C0r | 365000 N, Basic static load rating, radial |
Limiting speed | 3950 1/min |
Reference speed | 3550 1/min |
Cur | 54000 N, Fatigue limit load, radial |
e | 0.8 |
Y | 0.75 |
Y0 | 0.41 |
mass | 4.83 kg |
Nodes bearings have FAG T7FC085-XL roller bearings in stock, more related FAG bearings: FAG tapered roller bearings catalogue, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs.
