INA KR5201-2RS Stud type track rollers
Also known as : KR5201-2RS
- D: 35 mm
- d1: 12 mm
- B: 49.2 mm
- Cr: 8.7 kN
- C0r: 5.2 kN
INA KR5201-2RS Bearing
INA KR5201-2RS Cam Follower Bearing details
model | KR5201-2RS |
---|---|
D | 35 mm |
d1 | 12 mm |
B | 49.2 mm |
B1 max | 17 mm |
B2 | 32.5 mm |
C | 15.9 mm |
C1 | 0.8 mm |
d2 | 17.1 mm |
G | M12x1.5 |
IG | 17 mm |
Crowning radius | 500 mm |
rmin | 0.6 mm |
W | 6 mm, Nominal dimension for hexagonal socket |
MA | 45 mm |
Cr w | 8700 N, Effective dynamic load rating as track roller (radial) |
C0r w | 5200 N, Effective static load rating as track roller (radial) |
Cur w | 260 N, Fatigue limit load |
Speed | 7500 1/min, with continuous operation and grease lubrication |
mass | 0.12 kg |
INA KR5201-2RS bearings, INA stud type track rollers, ball bearing, double row, lip seals on both sides.
