INA NKIA5912-XL combined needle bearings | 60x85x34mm
Also known as : NKIA5912-XL
- Inside Diameter: 60 mm
- Outside Diameter: 85 mm
- Width: 34 mm
- Basic dynamic load rating: 12.4 kN
- Basic static load rating: 32 kN
INA NKIA5912-XL Bearing
INA NKIA5912-XL Bearing details
| Number | NKIA5912-XL | |
|---|---|---|
| Type |
Needle roller bearings Needle roller/angular contact ball bearings NKIA |
|
| d | 60 mm | |
| D | 85 mm | |
| B | 34 mm | |
| F | 68 mm | |
| rmin | 1 mm | |
| m | 590 g | Mass |
| Cr | 68000 N | Basic dynamic load rating, radial |
| C0r | 108000 N | Basic static load rating, radial |
| Ca | 12400 N | Basic dynamic load rating, axial |
| C0a | 32000 N | Basic static load rating, axial |
| Cur | 18800 N | Fatigue limit load, radial |
| Cua | 1410 N | Fatigue limit load, axial |
| nG | 6800 1/min | Limiting speed |
| nB | 5500 1/min | Reference speed |
As INA bearing distributor, Nodes bearings have INA NKIA5912-XL Needle roller/angular contact ball bearings in stock. NKIA5912-XL is single direction axial component, to DIN 5 429-2.
