INA NKX35-Z-XL Bearing

INA NKX35-Z-XL combined needle bearings | 35x47x30mm

Also known as : NKX35-Z-XL

• Inside Diameter: 35 mm
• Outside Diameter: 47 mm
• Width: 30 mm
• Basic dynamic load rating: 21.2 kN
• Basic static load rating: 47 kN

Inquire Now

INA NKX35-Z-XL Bearing

Number	NKX35-Z-XL
Type	Needle roller bearings Needle roller/axial ball bearings
Fw	35 mm
D	47 mm
C	30 mm	Tolerance: 0/-0,25
C1	12 mm	Tolerance: 0/-0,2
C2	9 mm
D2 max	53,2 mm
da	47,7 mm
dw	35 mm	Tolerance: E8
ra max	0,6 mm
rmin	0,6 mm
m	168 g	Mass
Cr	27500 N	Basic dynamic load rating, radial
C0r	41500 N	Basic static load rating, radial
Ca	21200 N	Basic dynamic load rating, axial
C0a	47000 N	Basic static load rating, axial
Cur	7300 N	Fatigue limit load, radial
Cua	2270 N	Fatigue limit load, axial
nG	4600 1/min	Limiting speed
	IR30X35X20-XL	Suitable inner ring

As INA bearing distributor, Nodes bearings have INA NKX35-Z-XL Needle roller/axial ball bearings in stock. NKX35-Z-XL is axial component, single direction, to DIN 5429, with end cap, for grease lubrication.
