INA RNAO20X28X26-ZW-ASR1-XL Bearing

INA RNAO20X28X26-ZW-ASR1-XL needle bearings

Also known as : RNAO20X28X26-ZW-ASR1-XL, RNAFW202826

• Inside Diameter: 20 mm
• Outside Diameter: 28 mm
• Width: 26 mm
• Basic dynamic load rating: 19 kN
• Basic static load rating: 28.5 kN

Inquire Now

INA RNAO20X28X26-ZW-ASR1-XL Bearing

Fw	20 mm
D	28 mm
C	26 mm
Da	24,3 mm
Db	20,4 mm
db	23,6 mm
E	24 mm
ra max	0,3 mm
rmin	0,3 mm
m	50 g	Mass
Cr	19000 N	Basic dynamic load rating, radial
C0r	28500 N	Basic static load rating, radial
Cur	4600 N	Fatigue limit load, radial
nG	21300 1/min	Limiting speed
nB	13700 1/min	Reference speed

As INA bearing distributor, Nodes bearings have INA RNAO20X28X26-ZW-ASR1-XL needle bearings in stock, without ribs, double row.
