INA RSL182213-A-XL Bearing

RSL182213-A-XL INA cylindrical roller bearings

Also known as :

• Inside Diameter: 65 mm
• Outside Diameter: 106.25 mm
• Width: 31 mm
• Basic dynamic load rating: 198 kN
• Basic static load rating: 210 kN

Inquire Now

INA RSL182213-A-XL Bearing

PN	RSL182213-A-XL
Brand	INA
Type	Cylindrical roller bearing
Tolerance class	PN	Normal (PN)
Number of rolling element rows	1	Single-row design
Main Dimensions & Performance Data
d	65 mm	Bore diameter
Ew	106.25 mm
B	31 mm	Width
Cr	198000 N	Basic dynamic load rating, radial
C0r	210000 N	Basic static load rating, radial
Cur	39500 N	Fatigue load limit, radial
nG	4200 1/min	Limiting speed
m	0.925 kg	Weight
Mounting dimensions
da min	82.3 mm	Minimum diameter shaft shoulder
Dimensions
r min	1.5 mm	Minimum chamfer dimension
d1	82.3 mm	Maximum rib diameter inner ring
Tk	91.25 mm	pitch circle

RSL182213-A-XL, INA brand, Cylindrical roller bearing RSL18..-XL, full complement roller set, single row, non-locating bearing, no outer ring, 2 ribs on inner ring, edge radius RV on one side, type RSL18
