INA SL024836 roller bearings
Also known as : SL024836, NNCL4836V
- Inside Diameter: 180 mm
- Outside Diameter: 225 mm
- Width: 45 mm
- Basic dynamic load rating: 270 kN
- Basic static load rating: 640 kN
INA SL024836 Bearing
INA SL024836 Bearing details
| model | SL024836 |
|---|---|
| d | 180 mm |
| D | 225 mm |
| B | 225 mm |
| C | 22.5 mm |
| d1 | 199.1 mm |
| E | 214.1 mm |
| rmin | 1.1 mm |
| s | 3 mm, Axial displacement |
| Cr | 270000 N |
| C0r | 640000 N |
| Cur | 72000 N, Fatigue limit load, radial |
| Limiting speed | 1070 1/min |
| Reference speed | 1560 1/min |
| mass | 4.15 kg |
INA SL024836 roller bearings, Designation to DIN 5412: NNCL4836V, Cylindrical roller bearings, non-locating bearing, double row, full complement cylindrical roller set
INA SL024836 bearing cross reference
INA SL014836 bearing
180mm x 225mm x 45mm
INA SL014936 bearing
180mm x 250mm x 69mm
INA SL024936 bearing
180mm x 250mm x 69mm
INA SL04180-PP bearing
180mm x 240mm x 80mm
INA SL045036-PP bearing
180mm x 280mm x 136mm
INA SL182236 bearing
180mm x 320mm x 86mm
INA SL182936-XL bearing
180mm x 250mm x 42mm
INA SL183036 bearing
180mm x 280mm x 74mm
INA SL185036-TB bearing
180mm x 280mm x 136mm
