INA SL024848 roller bearings
Also known as : SL024848, NNCL4848V
- Inside Diameter: 240 mm
- Outside Diameter: 300 mm
- Width: 60 mm
- Basic dynamic load rating: 510 kN
- Basic static load rating: 1260 kN
INA SL024848 Bearing
INA SL024848 Bearing details
| model | SL024848 |
|---|---|
| d | 240 mm |
| D | 300 mm |
| B | 300 mm |
| C | 30 mm |
| d1 | 259.5 mm |
| E | 281.9 mm |
| rmin | 2 mm |
| s | 4 mm, Axial displacement |
| Cr | 510000 N |
| C0r | 1260000 N |
| Cur | 143000 N, Fatigue limit load, radial |
| Limiting speed | 730 1/min |
| Reference speed | 1170 1/min |
| mass | 9.9 kg |
INA SL024848 roller bearings, Designation to DIN 5412: NNCL4848V, Cylindrical roller bearings, non-locating bearing, double row, full complement cylindrical roller set
