INA SL024918 roller bearings
Also known as : SL024918, NNCL4918V
- Inside Diameter: 90 mm
- Outside Diameter: 125 mm
- Width: 35 mm
- Basic dynamic load rating: 153 kN
- Basic static load rating: 290 kN
INA SL024918 Bearing
INA SL024918 Bearing details
model | SL024918 |
---|---|
d | 90 mm |
D | 125 mm |
B | 125 mm |
C | 17.5 mm |
d1 | 103 mm |
E | 115.2 mm |
rmin | 1.1 mm |
s | 1.5 mm, Axial displacement |
Cr | 153000 N |
C0r | 290000 N |
Cur | 39000 N, Fatigue limit load, radial |
Limiting speed | 1870 1/min |
Reference speed | 3050 1/min |
mass | 1.3 kg |
INA SL024918 roller bearings, Designation to DIN 5412: NNCL4918V, Cylindrical roller bearings, non-locating bearing, double row, full complement cylindrical roller set
