INA LR205-2RSR Bearing

INA LR205-2RSR track rollers

Also known as : LR205-2RSR,361205R

• Inside Diameter: 25 mm
• Outside Diameter: 62 mm
• Width: 15 mm
• Basic dynamic load rating: 13.3 kN
• Basic static load rating: 7.1 kN

Inquire Now

INA LR205-2RSR Bearing

model	LR205-2RSR
d	25 mm
D	62 mm
C	15 mm
d2	33.5 mm
R	500 mm, Crowning radius
rmin	1 mm
Cr w	13300 N, Effective dynamic load rating as track roller (radial)
C0r w	7100 N, Effective static load rating as track roller (radial)
Cur w	360 N, Fatigue limit load
speed	7000 1/min, (with continuous operation and grease lubrication)
mass	0.23 kg

INA LR205-2RSR track rollers, Track rollers, sealed on both sides.
