INA NATR15-PP Bearing

INA NATR15-PP Yoke type track rollers

Also known as : NATR15-PP, NART15UUR

• Inside Diameter: 15 mm
• Outside Diameter: 35 mm
• Width: 19 mm
• Basic dynamic load rating: 9.7 kN
• Basic static load rating: 14.3 kN

Inquire Now

INA NATR15-PP Bearing

d	15 mm
D	35 mm
B	19 mm
C	18 mm
d2	27,6 mm
rmin	0,6 mm
m	95 g	Mass
Cr w	9700 N	Effective dynamic load rating as track roller (radial)
C0r w	14300 N	Effective static load rating as track roller (radial)
Cur w	1830 N	Fatigue limit load
nD G	3600 1/min	Speed (with continuous operation and grease lubrication)
		Bearing with plastic axial plain washers and optimised INA profile. Permissible operating temperature: -30°C to + 100°C (continuous operation).

As INA bearing distributor, Nodes bearings have INA NATR15-PP Yoke type track rollers in stock, with axial guidance, axial plain washers on both sides.
