INA PWTR20-2RS-XL Yoke type track rollers
Also known as : PWTR20-2RS-XL
- Inside Diameter: 20 mm
- Outside Diameter: 47 mm
- Width: 25 mm
- Basic dynamic load rating: 24.5 kN
- Basic static load rating: 30.5 kN
INA PWTR20-2RS-XL Bearing
INA PWTR20-2RS-XL Bearing details
| d | 20 mm | |
|---|---|---|
| D | 47 mm | |
| B | 25 mm | |
| C | 24 mm | |
| d2 | 27 mm | |
| r1 min | 0,5 mm | |
| rmin | 1 mm | |
| m | 245 g | Mass |
| Cr w | 24500 N | Effective dynamic load rating as track roller (radial) |
| C0r w | 30500 N | Effective static load rating as track roller (radial) |
| Fr per | 20700 N | Permissible dynamic radial load |
| F0r per | 30500 N | Permissible static radial load |
| Cur w | 3750 N | Fatigue limit load |
| nD G | 3800 1/min | Speed (with continuous operation and grease lubrication) |
As INA bearing distributor, Nodes bearings have INA PWTR20-2RS-XL Yoke type track rollers in stock, full complement cylindrical roller set, with axial guidance, lip seals on both sides.
INA PWTR20-2RS-XL bearing cross reference
INA NA2204-2RSR bearing
20mm x 47mm x 18mm
INA NATR20 bearing
20mm x 47mm x 25mm
INA NATV20 bearing
20mm x 47mm x 25mm
INA NATR20-PP bearing
20mm x 47mm x 25mm
INA NATV20-PP bearing
20mm x 47mm x 25mm
INA PWTR2052-2RS-XL bearing
20mm x 52mm x 25mm
INA NUTR20 bearing
20mm x 47mm x 25mm
INA NUTR2052 bearing
20mm x 52mm x 25mm
INA RNA2202-2RSR bearing
20mm x 35mm x 13.8mm
INA PWTR20-2RS-RR-XL bearing
20mm x 47mm x 25mm
INA PWTR2052-2RS-RR-XL bearing
20mm x 52mm x 25mm
