KAYDON KA070XP0 Bearing

KAYDON KA070XP0 thin section bearings

Also known as : KA070XP0

  • Inside Diameter: 7 inches
  • Outside Diameter: 7.5 inches
  • Width: 0.25 inches
  • Basic dynamic load rating: 1046 lbs
  • Basic static load rating: 5500 lbs

Inquire Now


KAYDON KA070XP0 Bearing

KAYDON KA070XP0 Bearing details

Kaydon part number KA070XP0
Bore 7.000 inches
Outside dia. 7.500 inches
Width 0.25 inches
Land dia. L1 7.186 inches
Land dia. L2 7.314 inches
Dynamic radial 1,046 lbs
Dynamic thrust 1,730 lbs
Dynamic moment 2,844 lbs
Static radial 2,200 lbs
Static thrust 5,500 lbs
Static moment 7,980 lbs
Approx. weight 0.310 lbs

As KAYDON bearings distributor, Nodes bearings have KAYDON KA070XP0 open thin section bearings in stock, Reali-Slim open bearings, KA series, Type X -- four-point contact.

KAYDON KA070XP0 bearing cross reference

KAYDON KA070AR0 bearing
7.000" x 7.500" x 0.25"
KAYDON KA070CP0 bearing
7.000" x 7.500" x 0.25"
KAYDON KB070AR0 bearing
7.000" x 7.625" x 0.3125"
KAYDON KB070CP0 bearing
7.000" x 7.625" x 0.3125"
KAYDON KB070XP0 bearing
7.000" x 7.625" x 0.3125"
KAYDON KC070AR0 bearing
7.000" x 7.750" x 0.375"
KAYDON KC070CP0 bearing
7.000" x 7.750" x 0.375"
KAYDON KC070XP0 bearing
7.000" x 7.750" x 0.375"
KAYDON KD070AR0 bearing
7.000" x 8.000" x 0.5"
KAYDON KD070CP0 bearing
7.000" x 8.000" x 0.5"
KAYDON KD070XP0 bearing
7.000" x 8.000" x 0.5"
KAYDON KF070AR0 bearing
7.000" x 8.500" x 0.75"
