NSK 51113 Thrust Ball Bearings
Also known as : 51113
- Inside Diameter: 65 mm
- Outside Diameter: 90 mm
- Width: 18 mm
- Basic dynamic load rating: 42 kN
- Basic static load rating: 117 kN

NSK 51113 Bearing
NSK 51113 Bearing details
model | 51113 |
---|---|
d | 65 mm |
D | 90 mm |
T | 18 mm |
d1 | 90 mm |
D1 | 67 mm |
rmin. | 1.0 mm |
Ca | 42000 N |
C0a | 117000 N |
Limiting speeds | 2400 min-1 (Grease) |
Limiting speeds | 3800 min-1 (Oil) |
da | 80 mm |
Da | 75 mm |
ra | 1.0 mm |
Mass | 0.324 kg (approx.) |
As a NSK Bearing distributor, Nodes bearings have NSK 51113 thrust ball bearings in stock. more related bearings: Thrust ball bearings.

NSK 51113 bearing cross reference

SKF 51113 bearing
65mm x 90mm x 18mm

NSK 51213 bearing
65mm x 100mm x 27mm

NSK 51313 bearing
65mm x 115mm x 36mm

NSK 51413 bearing
65mm x 140mm x 56mm

NSK 53213 bearing
65mm x 100mm x 28.7mm

NSK 53313 bearing
65mm x 115mm x 39.4mm

NSK 53413 bearing
65mm x 140mm x 60.2mm

NSK 53213U bearing
65mm x 100mm x 32mm

NSK 53313U bearing
65mm x 115mm x 43mm

NSK 53413U bearing
65mm x 140mm x 65mm
