NSK 7216C Angular Contact Ball Bearings
Also known as : 7216C
- Inside Diameter: 80 mm
- Outside Diameter: 140 mm
- Width: 26 mm
- Basic dynamic load rating: 93 kN
- Basic static load rating: 77.5 kN
NSK 7216C Bearing
NSK 7216C Bearing details
model | 7216C |
---|---|
d | 80 mm |
D | 140 mm |
B | 26 mm |
a | 27.7 mm |
rmin. | 2.0 mm |
r1 min. | 1.00 mm |
Cr | 93000 N 9450 kgf |
C0r | 77500 N 7900 kgf |
Limiting speeds | 7500 min-1 (Grease) |
Limiting speeds | 10000 min-1 (Oil) |
da | 90.0 mm |
Da | 130.0 mm |
ra | 2.0 mm |
Mass | 1.630 kg (approx.) |
As a NSK Bearing distributor, Nodes bearings have NSK 7216C ball bearings in stock, C: Contact Angle of 15°, single row. more related NSK bearings: NSK angular contact ball bearings catalogue.
