NSK 7305B Bearing

NSK 7305B Angular Contact Ball Bearings

Also known as : 7305B

  • Inside Diameter: 25 mm
  • Outside Diameter: 62 mm
  • Width: 17 mm
  • Basic dynamic load rating: 24.4 kN
  • Basic static load rating: 14.6 kN

Inquire Now


NSK 7305B Bearing

NSK 7305B Bearing details

model 7305B
d 25 mm
D 62 mm
B 17 mm
a 26.7 mm
rmin. 1.1 mm
r1 min. 0.60 mm
Cr 24400 N
2490 kgf
C0r 14600 N
1490 kgf
Limiting speeds 9000 min-1 (Grease)
Limiting speeds 13000 min-1 (Oil)
da 32.0 mm
Da 55.0 mm
ra 1.0 mm
Mass 0.241 kg (approx.)

As a NSK Bearing distributor, Nodes bearings have NSK 7305B ball bearings in stock, B: Contact Angle of 40°, single row. more related NSK bearings: NSK angular contact ball bearings catalogue.

NSK 7305B bearing cross reference

FAG 7305-B-XL-JP bearing
25mm x 62mm x 17mm
FAG 7305-B-XL-MP bearing
25mm x 62mm x 17mm
FAG 7305-B-TVP bearing
25mm x 62mm x 17mm
SKF 7305 BECBY bearing
25mm x 62mm x 17mm
SKF 7305 BEY bearing
25mm x 62mm x 17mm
SKF 7305 BEGBY bearing
25mm x 62mm x 17mm
NSK 7905A5 bearing
25mm x 42mm x 9mm
NSK 7205B bearing
25mm x 52mm x 15mm
NSK 7905C bearing
25mm x 42mm x 9mm
NSK 7005C bearing
25mm x 47mm x 12mm
NSK 7205C bearing
25mm x 52mm x 15mm
NSK 7005A bearing
25mm x 47mm x 12mm
