NSK 22206CKE4 Spherical roller bearings | 30x62x20.0mm
Also known as : 22206CKE4
- Inside Diameter: 30 mm
- Outside Diameter: 62 mm
- Width: 20 mm
- Basic dynamic load rating: 50 kN
- Basic static load rating: 50 kN
NSK 22206CKE4 Bearing
NSK 22206CKE4 Bearing details
Bearing number | 22206CKE4 |
---|---|
Type | Spherical roller bearings |
Brand | NSK |
d | 30 mm |
D | 62 mm |
B | 20.0 mm |
rmin. | 1.0 mm |
Cr |
50000 N 5100 kgf |
C0r |
50000 N 5100 kgf |
Limiting speeds | 6000 min-1 (Grease) |
Limiting speeds | 7500 min-1 (Oil) |
da min | 36 mm |
da max | 37 mm |
Da max | 56 mm |
Da min | 54 mm |
ra | 1.0 mm |
Constant | 0.33 |
Y2 | 3.1 Axial Load Factors |
Y3 | 2.1 Axial Load Factors |
Y0 | 2 Axial Load Factors |
Mass | 0.27 kg (approx.) |
NSK 22206CKE4 roller bearings with Tapered Bore, spherical roller bearing, double-Row.
