NSK NU209EW Cylindrical roller bearings
Also known as : NU209EW, NU209ECJ
- Inside Diameter: 45 mm
- Outside Diameter: 85 mm
- Width: 19 mm
- Basic dynamic load rating: 63 kN
- Basic static load rating: 66.5 kN
NSK NU209EW Bearing
NSK NU209EW Bearing details
| model | NU209EW |
|---|---|
| d | 45 mm |
| D | 85 mm |
| B | 19 mm |
| rmin. | 1.1 mm |
| r1 min. | 1.1 mm |
| Fw | 54.5 mm |
| Cr |
63000 N 6450 kgf |
| C0r |
66500 N 6800 kgf |
| Limiting speeds | 6700 min-1 (Grease) |
| Limiting speeds | 8000 min-1 (Oil) |
| db min | 51.5 mm |
| db max | 52 mm |
| Da | 78.5 mm |
| ra | 1.0 mm |
| rb | 1 mm |
| Mass | 0.438 kg (approx.) |
NSK NU209EW roller bearings, NU type, cylindrical roller bearings, single-Row.
