NSK NU210ETC3 Cylindrical roller bearings
Also known as : NU210EW, NU210ECJ
- Inside Diameter: 50 mm
- Outside Diameter: 90 mm
- Width: 20 mm
- Basic dynamic load rating: 69 kN
- Basic static load rating: 76.5 kN
NSK NU210ETC3 Bearing
NSK NU210ETC3 Bearing details
model | NU210ETC3 |
---|---|
d | 50 mm |
D | 90 mm |
B | 20 mm |
rmin. | 1.1 mm |
r1 min. | 1.1 mm |
Fw | 59.5 mm |
Cr |
69000 N 7050 kgf |
C0r |
76500 N 7800 kgf |
Limiting speeds | 6300 min-1 (Grease) |
Limiting speeds | 7500 min-1 (Oil) |
db min | 56.5 mm |
db max | 57 mm |
Da | 83.5 mm |
ra | 1.0 mm |
rb | 1 mm |
Mass | 0.500 kg (approx.) |
NSK NU210EW roller bearings, NU type, cylindrical roller bearings, single-Row.
