NSK NU2206ET Cylindrical roller bearings
Also known as : NU2206ET, NU2206
- Inside Diameter: 30 mm
- Outside Diameter: 62 mm
- Width: 20 mm
- Basic dynamic load rating: 49 kN
- Basic static load rating: 50 kN
NSK NU2206ET Bearing
NSK NU2206ET Bearing details
| model | NU2206ET |
|---|---|
| d | 30 mm |
| D | 62 mm |
| B | 20 mm |
| rmin. | 1.0 mm |
| r1 min. | 0.6 mm |
| Fw | 37.5 mm |
| Cr |
49000 N 5000 kgf |
| C0r |
50000 N 5100 kgf |
| Limiting speeds | 9500 min-1 (Grease) |
| Limiting speeds | 12000 min-1 (Oil) |
| db min | 34 mm |
| db max | 36 mm |
| Da | 57.0 mm |
| ra | 1.0 mm |
| rb | 0.6 mm |
| Mass | 0.255 kg (approx.) |
NSK NU2206ET roller bearings, NU type, cylindrical roller bearings, single-Row.
NSK NU2206ET bearing cross reference
NSK NU1006 bearing
30mm x 55mm x 13mm
NSK NU206EW bearing
30mm x 62mm x 16mm
NSK NU2206 bearing
30mm x 62mm x 20mm
NSK NU306EW bearing
30mm x 72mm x 19mm
NSK NU2306 bearing
30mm x 72mm x 27mm
NSK NU2306ET bearing
30mm x 72mm x 27mm
NSK NU406 bearing
30mm x 90mm x 23mm
FAG NU2206-E-XL-TVP2 bearing
30mm x 62mm x 20mm
NTN NU2206E bearing
30mm x 62mm x 20mm
NSK N206M bearing
30mm x 62mm x 16mm
NSK N306M bearing
30mm x 72mm x 19mm
