NSK NU305EW Cylindrical roller bearings
Also known as : NU305EW, NU305ECJ
- Inside Diameter: 25 mm
- Outside Diameter: 62 mm
- Width: 17 mm
- Basic dynamic load rating: 41.5 kN
- Basic static load rating: 37.5 kN
NSK NU305EW Bearing
NSK NU305EW Bearing details
| model | NU305EW |
|---|---|
| d | 25 mm |
| D | 62 mm |
| B | 17 mm |
| rmin. | 1.1 mm |
| r1 min. | 1.1 mm |
| Fw | 34 mm |
| Cr |
41500 N 4250 kgf |
| C0r |
37500 N 3800 kgf |
| Limiting speeds | 10000 min-1 (Grease) |
| Limiting speeds | 12000 min-1 (Oil) |
| db min | 31.5 mm |
| db max | 32 mm |
| Da | 55.5 mm |
| ra | 1.0 mm |
| rb | 1 mm |
| Mass | 0.269 kg (approx.) |
NSK NU305EW roller bearings, NU type, cylindrical roller bearings, single-Row.
