NTN 7330B Bearing

NTN 7330B bearings | 150x320x65mm

Also known as : 7330B

  • Inside Diameter: 150 mm
  • Outside Diameter: 320 mm
  • Width: 65 mm
  • Basic dynamic load rating: 300 kN
  • Basic static load rating: 350 kN

Inquire Now


NTN 7330B Bearing

NTN 7330B Bearing details

Part Number 7330B
Brand NTN
Mass 25.1 kg
Boundary dimensions (mm)
Inner dia. (d) 150
Outer dia. (D) 320
Width (B) 65
Chamfer (rs_min) 4
Basic load ratings (kN)
Dynamic (Cr) 300
Static (Cor) 350
Basic load ratings (kgf)
Dynamic (Cr) 30500
Static (Cor) 36000
Limiting speed (min-1)
Grease 2000
Oil 2600
Abutment and fillet dimensions (mm)
da min 168
Da max 311.5
ras max 1.5

Nodes have NTN 7330B bearings in stock. 7330B, single row angular contact ball bearing.

NTN 7330B bearing cross reference

FAG 7330-B-MP-UA bearing
150mm x 320mm x 65mm
SKF 7330 BCBM bearing
150mm x 320mm x 65mm
NSK 7330ADB bearing
150mm x 320mm x 65mm
NSK 7330BDB bearing
150mm x 320mm x 65mm
NSK 7330ADF bearing
150mm x 320mm x 65mm
NSK 7330BDF bearing
150mm x 320mm x 65mm
NSK 7330ADT bearing
150mm x 320mm x 65mm
NSK 7330BDT bearing
150mm x 320mm x 65mm
NTN 7930 bearing
150mm x 210mm x 28mm
NTN 7030 bearing
150mm x 225mm x 35mm
NTN 7230 bearing
150mm x 270mm x 45mm
NTN 7230B bearing
150mm x 270mm x 45mm
