NTN NJ2324E bearings | 120x260x86mm
Also known as : NJ2324E
- Inside Diameter: 120 mm
- Outside Diameter: 260 mm
- Width: 86 mm
- Basic dynamic load rating: 795 kN
- Basic static load rating: 1030 kN
NTN NJ2324E Bearing
NTN NJ2324E Bearing details
| Part Number | NJ2324E |
|---|---|
| Brand | NTN |
| Type | Cylindrical roller bearings NJ type |
| Mass | - kg |
| Boundary dimensions (mm) | |
| Inner dia. (d) | 120 |
| Outer dia. (D) | 260 |
| Width (B) | 86 |
| Chamfer (rs_min) | 3 |
| Basic load ratings (kN) | |
| Dynamic (Cr) | 795 |
| Static (Cor) | 1030 |
| Basic load ratings (kgf) | |
| Dynamic (Cr) | 81000 |
| Static (Cor) | 105000 |
| Limiting speed (min-1) | |
| Grease | 2200 |
| Oil | 2500 |
| Abutment and fillet dimensions (mm) | |
| da min | 133 |
| Da max | 247 |
| ras max | 2.5 |
Nodes have NTN NJ2324E bearings in stock. NJ2324E, single row cylindrical roller bearings (Type NJ).
NTN NJ2324E bearing cross reference
SKF NJ2324ECML/C3 bearing
120mm x 260mm x 86mm
TIMKEN NJ2324EMA bearing
120mm x 260mm x 86mm
NTN NU1024 bearing
120mm x 180mm x 28mm
NTN NU224E bearing
120mm x 215mm x 40mm
NTN NU2224E bearing
120mm x 215mm x 58mm
NTN NU324 bearing
120mm x 260mm x 55mm
NTN NU2324E bearing
120mm x 260mm x 86mm
NTN NJ1024 bearing
120mm x 180mm x 28mm
NTN NJ224E bearing
120mm x 215mm x 40mm
NTN NJ2224E bearing
120mm x 215mm x 58mm
NTN NJ324E bearing
120mm x 260mm x 55mm
