SKF 3208 ATN9 Bearing

3208 ATN9 SKF bearings, double row

Also known as : 5208

• Inside Diameter: 40 mm
• Outside Diameter: 80 mm
• Width: 30.2 mm
• Basic dynamic load rating: 48 kN
• Basic static load rating: 36.5 kN

Inquire Now

SKF 3208 ATN9 Bearing

3208 ATN9 SKF

Part Number	3208 ATN9
Brand	SKF
Description	Double row angular contact ball bearing High speed capability
Contact angle	30 °
Cage	Glass fibre reinforced PA66 cage, ball centred
Dimensions
d	40 mm	Bore diameter
D	80 mm	Outside diameter
B	30.2 mm	Width
d2	47.8 mm	Recess diameter inner ring shoulder
D2	82.1 mm	Shoulder diameter of outer ring (large side face)
r1,2	min. 1.1 mm	Chamfer dimension inner ring
a	46 mm	Distance pressure point(s)
Abutment dimensions
da	min. 47 mm	Abutment diameter shaft
Da	max. 73 mm	Abutment diameter housing
ra	max. 1 mm	Radius of fillet
Calculation data
C	48 kN	Basic dynamic load rating
C0	36.5 kN	Basic static load rating
Pu	1.56 kN	Fatigue load limit
Limiting speed	8000 r/min
Kr	0.06	Calculation factor
e	0.8	Limiting value
Mass
Mass	0.57 kg
