SKF 608-2Z single row deep groove ball bearings
Also known as : 608-2Z, 608ZZ
- Inside Diameter: 8 mm
- Outside Diameter: 22 mm
- Width: 7 mm
- Basic dynamic load rating: 3.4 kN
- Basic static load rating: 1.3 kN
SKF 608-2Z Bearing
SKF 608-2Z Bearing details
model | 608-2Z |
---|---|
d | 8 mm |
D | 22 mm |
B | 7 mm |
d1 | 12.1 mm |
D2 | 19.2 mm |
r1,2 min. | mm |
da min | 10 mm |
da max | 12 mm |
Da max | 20 mm |
ra max | 0.3 mm |
C | 3.4 kN, Basic dynamic load rating |
C0 | 1.3 kN, Basic static load rating |
Pu | 0.05 kN, Fatigue load limit |
Reference speed | 75000 r/min |
Limiting speed | 38000 r/min |
kr | 0.025, Calculation factor |
f0 | 12, Calculation factor |
Mass | 0.0125 kg |
SKF 608-2Z ball bearings, SKF Explorer, deep groove ball bearing, Single-Row, Shield on both sides.
