SKF NU 2215 ECP Bearing

NU 2215 ECP SKF cylindrical roller bearings

Also known as : NU2215-E-TVP

• Inside Diameter: 75 mm
• Outside Diameter: 130 mm
• Width: 31 mm
• Basic dynamic load rating: 186 kN
• Basic static load rating: 208 kN

Inquire Now

SKF NU 2215 ECP Bearing

Part Number	NU 2215 ECP
Brand	SKF, SKF Explorer
Catagory	Cylindrical roller bearings, single row
d	75 mm, Bore diameter
D	130 mm, Outside diameter
B	31 mm, Width
D1	113.3 mm, Shoulder diameter of outer ring
F	88.5 mm, Raceway diameter of inner ring
r1,2 min	1.5 mm, Chamfer dimension
r3,4 min	1.5 mm, Chamfer dimension outer ring small side face
smax.	1.7 mm, Permissible axial displacement
ABUTMENT DIMENSIONS
da min	84 mm, Diameter of spacer sleeve
da max.	86 mm, Diameter of spacer sleeve
db min	91 mm, Diameter of shaft abutment
Da max	121.5 mm, Diameter of housing abutment
ra max	1.5 mm, Radius of fillet
rb max	1.5 mm, Radius of fillet
CALCULATION DATA
C	186 kN, Basic dynamic load rating
C0	208 kN, Basic static load rating
Pu	27 kN, Fatigue load limit
Reference speed	5600 r/min
Limiting speed	6000 r/min
MASS
Mass bearing	1.56 kg

SKF NU 2215 ECP, Cylindrical roller bearings, single row. NU2215ECP bearings are designed to accommodate high radial loads in combination with high speed.
P : Glass fibre reinforced PA66 cage, rolling element centred
