SKF NNF5018ADA-2LSV roller bearings
Also known as : NNF5018ADA-2LSV, SL045018pp
- Inside Diameter: 90 mm
- Outside Diameter: 140 mm
- Width: 67 mm
- Basic dynamic load rating: 319 kN
- Basic static load rating: 550 kN
SKF NNF5018ADA-2LSV Bearing
SKF NNF5018ADA-2LSV Bearing details
model | NNF5018ADA-2LSV |
---|---|
d | 90 mm |
D | 140 mm |
B | 67 mm |
C | 66 mm |
d1 | 109.5 mm |
D3 | 137 mm |
C1 | 59.2 mm |
C2 | 3.4 mm |
b | 4.2 mm |
b1 | 6 mm |
K | 3.5 mm |
r | 1.5 mm |
r3,4 min. | 0.6 mm |
da min | 96 mm |
das | 106 mm |
Ca1 | 54 mm |
Ca2 | 51 mm |
ra max | 1 mm |
Ca1 applies for SW snap rings and Ca2 for snap rings in accordance with DIN 471 |
|
C | 319 kN, Basic dynamic load rating |
C0 | 550 kN, Basic static load rating |
Pu | 69.5 kN, Fatigue load limit |
Reference speed | 900 r/min |
Limiting speed | 900 r/min |
Kr | 0.4, Calculation factor |
Snap ring Seeger | SW 140 |
Snap ring in accordance with DIN 471 | 140x4 |
Mass | 3.71 kg |
