SKF NU311ECM Bearing

SKF NU311ECM cylindrical roller bearings

Also known as : NU311ECM, NU311B-MP

• Inside Diameter: 55 mm
• Outside Diameter: 120 mm
• Width: 29 mm
• Basic dynamic load rating: 156 kN
• Basic static load rating: 143 kN

Inquire Now

SKF NU311ECM Bearing

model	NU311ECM
d	55 mm
D	120 mm
B	29 mm
D1	100.3 mm
F	70.5 mm
r1,2 min.	2 mm
r3,4 min.	2 mm
smax.	2 mm
da min	65 mm
da max	68 mm
db min	73 mm
Da max	109.2 mm
ra max	2 mm
rb max	2 mm
C	156 kN, Basic dynamic load rating
C0	143 kN, Basic static load rating
Pu	18.6 kN, Fatigue load limit
Reference speed	6000 r/min
Limiting speed	7000 r/min
Kr	0.15, Calculation factor
e	0.2, Limiting value
Y	0.6, Axial load factor
Angle ring	HJ 311 EC
Mass	1.72 kg
