SKF NU313ECM cylindrical roller bearings
Also known as : NU313ECM, NU313B-MP
- Inside Diameter: 65 mm
- Outside Diameter: 140 mm
- Width: 33 mm
- Basic dynamic load rating: 212 kN
- Basic static load rating: 196 kN
SKF NU313ECM Bearing
SKF NU313ECM Bearing details
model | NU313ECM |
---|---|
d | 65 mm |
D | 140 mm |
B | 33 mm |
D1 | 117.4 mm |
F | 82.5 mm |
r1,2 min. | 2.1 mm |
r3,4 min. | 2.1 mm |
smax. | 2.2 mm |
da min | 77 mm |
da max | 80 mm |
db min | 85 mm |
Da max | 127.8 mm |
ra max | 2 mm |
rb max | 2 mm |
C | 212 kN, Basic dynamic load rating |
C0 | 196 kN, Basic static load rating |
Pu | 25.5 kN, Fatigue load limit |
Reference speed | 5300 r/min |
Limiting speed | 6000 r/min |
Kr | 0.15, Calculation factor |
e | 0.2, Limiting value |
Y | 0.6, Axial load factor |
Angle ring | HJ 313 EC |
Mass | 2.55 kg |
Nodes bearings, SKF single row cylindrical roller bearings wholesaler, have SKF NU313ECM roller bearings in stock, SKF Explorer, Cylindrical roller bearings, single row.
