TIMKEN 16008 Deep Groove Ball Bearings | 40x68x9mm
Also known as : 16008
- Inside Diameter: 40 mm
- Outside Diameter: 68 mm
- Width: 9 mm
- Basic dynamic load rating: 12.6 kN
- Basic static load rating: 9.7 kN
TIMKEN 16008 Bearing
TIMKEN 16008 Bearing details
| Bearing Number | 16008 |
|---|---|
| Brand | TIMKEN |
| Type | Deep groove ball bearings |
| Clearance | C0 (Normal) |
| Bore Size d | 40.000 mm |
| Features | Open |
| Weight | 0.130 Kg |
| Outside Diameter D | 68.000 mm |
| Outside Ring Width B | 9.000 mm |
| Radius Rs min | 0.300 mm |
| Cr - Dynamic Load Rating | 12.6 kN |
| C0r - Static Load Rating | 9.7 kN |
| Grease Limiting Speed | 7400 rpm |
| Oil Limiting Speed | 11000 rpm |
As TIMKEN bearing distributor, Nodes bearings have TIMKEN 16008 bearings in stock. Timken 16000 narrow series have bore sizes that range from 10 to 160 mm and outside diameter sizes that range from 28 to 240mm.
TIMKEN 16008 bearing cross reference
NSK 16008 bearing
40mm x 68mm x 9mm
SKF 16008 bearing
40mm x 68mm x 9mm
FAG 16008 bearing
40mm x 68mm x 9mm
TIMKEN 6008-2RS bearing
40mm x 68mm x 15mm
TIMKEN 6208-2RS bearing
40mm x 80mm x 18mm
TIMKEN 6308-2RS bearing
40mm x 90mm x 23mm
TIMKEN 6008-2RS-NR bearing
40mm x 68mm x 15mm
TIMKEN 6208-2RS-NR bearing
40mm x 80mm x 18mm
TIMKEN 6308-2RS-NR bearing
40mm x 90mm x 23mm
TIMKEN 6008-N bearing
40mm x 68mm x 15mm
TIMKEN 6208-N bearing
40mm x 80mm x 18mm
