TIMKEN 208K Bearing

TIMKEN Fafnir 208K, 208PP Deep groove ball bearings | 40x80x

Also known as : 208K

  • Inside Diameter: 40 mm
  • Outside Diameter: 80 mm
  • Width: 18 mm
  • Basic dynamic load rating: 36.2 kN
  • Basic static load rating: 19.8 kN

Inquire Now


TIMKEN 208K Bearing

TIMKEN 208K Bearing details

Bearing Number 208K
Brand TIMKEN
Type Deep groove ball bearings
Design Units METRIC
Ball Type Steel
Bearing Weight 0.376 Kg
0.83 lb
d - Bore 40.000 mm
1.5748 in
D - Outer Diameter 80.000 mm
3.1496 in
Bearing Width 18.000 mm
0.7087 in
do - Ball Diameter 12.70000 mm
0.50000 in
Ce - Dynamic Radial Rating1 36200 N
8130 lbf
C0 - Static Radial Rating 19800 N
4460 lbf
Limiting Speed (Grease) 5000 rpm
Limiting Speed (Oil) 5830 rpm
R - Inner Ring "To Clear" Radius2 1.100 mm
0.043 in
r - Outer Ring "To Clear" Radius3 1.100 mm
0.043 in
da - Inner Ring Backing Diameter 43.900 mm
1.730 in
Da - Outer Ring Backing Diameter 72.900 mm
2.870 in

As TIMKEN bearing distributor, Nodes bearings have TIMKEN 208K bearings in stock. Radial ball bearings consist of an inner and outer ring with a cage containing a complement of precision balls.
