TIMKEN 6218M-C3 Bearing

TIMKEN 6218M-C3 Deep Groove Ball Bearings | 90x160x30mm

Also known as : 6218M-C3

• Inside Diameter: 90 mm
• Outside Diameter: 160 mm
• Width: 30 mm
• Basic dynamic load rating: 96 kN
• Basic static load rating: 71.5 kN

Inquire Now

TIMKEN 6218M-C3 Bearing

Bearing Number	6218M-C3
Brand	TIMKEN
Type	Deep groove ball bearings
Clearance	C3
Bore Size d	90.000 mm
Features	Open With Brass Cage
Weight	2.230 Kg
Outside Diameter D	160.000 mm
Outside Ring Width B	30.000 mm
Radius Rs min	2.000 mm
Cr - Dynamic Load Rating	96 kN
C0r - Static Load Rating	71.5 kN
Grease Reference Speed	4800 rpm
Oil Reference Speed	6900 rpm

As TIMKEN bearing distributor, Nodes bearings have TIMKEN 6218M-C3 bearings in stock. Deep groove ball bearings are available in a variety of sizes and are the most popular of the rolling bearings. This type of bearing supports radial load and a small degree of axial load in both directions simultaneously.
