TIMKEN 6405 Bearing

TIMKEN 6405 Deep Groove Ball Bearings | 25x80x21mm

Also known as : 6405

• Inside Diameter: 25 mm
• Outside Diameter: 80 mm
• Width: 21 mm
• Basic dynamic load rating: 36.1 kN
• Basic static load rating: 18.8 kN

Inquire Now

TIMKEN 6405 Bearing

Bearing Number	6405
Brand	TIMKEN
Type	Deep groove ball bearings
Clearance	C0 (Normal)
Bore Size d	25.000 mm
Features	Open
Weight	0.530 Kg
Outside Diameter D	80.000 mm
Outside Ring Width B	21.000 mm
Radius Rs min	1.500 mm
Cr - Dynamic Load Rating	36.1 kN
C0r - Static Load Rating	18.8 kN
Grease Reference Speed	10000 rpm
Oil Reference Speed	15000 rpm

As TIMKEN bearing distributor, Nodes bearings have TIMKEN 6405 bearings in stock. Deep groove ball bearings are available in a variety of sizes and are the most popular of the rolling bearings. This type of bearing supports radial load and a small degree of axial load in both directions simultaneously.
