TIMKEN NU2224EMA Cylindrical Roller Bearings | 120x215x58mm
Also known as : NU2224EMA
- Inside Diameter: 120 mm
- Outside Diameter: 215 mm
- Width: 58 mm
- Basic dynamic load rating: 514 kN
- Basic static load rating: 630 kN
TIMKEN NU2224EMA Bearing
TIMKEN NU2224EMA Bearing details
Bearing Number | NU2224EMA |
---|---|
Brand | TIMKEN |
Type | Cylindrical roller bearings |
Design Units | METRIC |
Bearing Weight | 9 Kg 19.8 lb |
Type | N U |
Tapered Bore | N |
d - Bore | 120 mm 4.7244 in |
D - Outer Diameter | 215.000 mm 8.4646 in |
C - Inner Ring Width | 58.000 mm 2.2835 in |
B - Outer Ring Width | 58.000 mm 2.2835 in |
C0 - Static Radial Rating | 630000 N 142000 lbf |
C - Dynamic Radial Rating1 | 514000 N 116000 lbf |
Reference Thermal Speed Rating (Grease) | 2200 |
Reference Thermal Speed Rating (Oil)2 | 2500 |
Cg - Geometry Factor3 | 0.1196 |
R - Inner Ring "To Clear" Radius4 | 2.000 mm 0.100 in |
r - Outer Ring "To Clear" Radius5 | 2.000 mm 0.100 in |
da - Inner Ring Backing Diameter | 137.000 mm 5.400 in |
Da - Outer Ring Backing Diameter | 0.000 mm 0.000 in |
1 Based on 1 X 106 L10 life for the ISO life calculation method.
2 See thermal speed ratings in the engineering section.
3 Geometry constant for Lubrication Life Adjustment Factor a3l.
4 Maximum housing fillet radius that bearing corners will clear.
5 Maximum shaft fillet radius that bearing corners will clear.
As TIMKEN bearing distributor, Nodes bearings have TIMKEN NU2224EMA bearings in stock.
