FAG 2205-K-2RS-TVH-C3 Bearing

FAG 2205-K-2RS-TVH-C3 bearings

Also known as : 2205-K-2RS-TVH-C3

• Inside Diameter: 25 mm
• Outside Diameter: 52 mm
• Width: 18 mm
• Basic dynamic load rating: 12.3 kN
• Basic static load rating: 3.25 kN

Inquire Now

FAG 2205-K-2RS-TVH-C3 Bearing

d	25 mm
D	52 mm
B	18 mm
D2	45,3 mm
Da max	46,4 mm
d2	30,7 mm
da max	32 mm
da min	30,6 mm
ra max	1 mm
rmin	1 mm
m	0,157 kg	Mass
Cr	12300 N	Basic dynamic load rating, radial
C0r	3250 N	Basic static load rating, radial
e	0,27
Y1	2,37
Y2	3,66
Y0	2,48
nG	8100 1/min	Limiting speed
Cur	203 N	Fatigue limit load, radial
	H305	Designation, adapter sleeve

As FAG bearing distributor, Nodes bearings have FAG 2205-K-2RS-TVH-C3 self aligning ball bearings in stock, main dimensions to DIN 630, with tapered bore, taper 1:12, lip seals on both sides.
