FAG 61860-M bearings
Also known as : 61860-M
- Inside Diameter: 300 mm
- Outside Diameter: 380 mm
- Width: 38 mm
- Basic dynamic load rating: 152 kN
- Basic static load rating: 206 kN
FAG 61860-M Bearing
FAG 61860-M Bearing details
| d | 300 mm | |
|---|---|---|
| D | 380 mm | |
| B | 38 mm | |
| D1 | 354,7 mm | |
| Da max | 369,8 mm | |
| d1 | 326,2 mm | |
| da min | 310,2 mm | |
| ra max | 2,1 mm | |
| rmin | 2,1 mm | |
| m | 8,97 kg | Mass |
| Cr | 152000 N | Basic dynamic load rating, radial |
| C0r | 206000 N | Basic static load rating, radial |
| Cur | 6300 N | Fatigue limit load, radial |
| nG | 2900 1/min | Limiting speed |
| nB | 1850 1/min | Reference speed |
| f0 | 16,1 | Calculation factor |
As FAG bearing distributor, Nodes bearings have FAG 61860-M deep groove ball bearings in stock, main dimensions to DIN 625-1.
FAG 61860-M bearing cross reference
FAG 61860-M bearing
300mm x 380mm x 38mm
NSK 6860 bearing
300mm x 380mm x 38mm
FAG 16060-M bearing
300mm x 460mm x 50mm
FAG 6060-M bearing
300mm x 460mm x 74mm
FAG 61860 bearing
300mm x 380mm x 38mm
FAG 61860-MA bearing
300mm x 380mm x 38mm
FAG 60860-M bearing
300mm x 380mm x 25mm
FAG 61960-MA bearing
300mm x 420mm x 56mm
