FAG 6306-2RSR bearings
Also known as : 6306-2RSR
- Inside Diameter: 30 mm
- Outside Diameter: 72 mm
- Width: 19 mm
- Basic dynamic load rating: 30.5 kN
- Basic static load rating: 16.2 kN
FAG 6306-2RSR Bearing
FAG 6306-2RSR Bearing details
d | 30 mm | |
---|---|---|
D | 72 mm | |
B | 19 mm | |
D2 | 61,6 mm | |
Da max | 65 mm | |
d1 | 44,6 mm | |
da min | 37 mm | |
ra max | 1 mm | |
rmin | 1,1 mm | |
m | 0,365 kg | Mass |
Cr | 30500 N | Basic dynamic load rating, radial |
C0r | 16200 N | Basic static load rating, radial |
Cur | 1120 N | Fatigue limit load, radial |
nG | 6000 1/min | Limiting speed |
As FAG bearing distributor, Nodes bearings have FAG 6306-2RSR deep groove ball bearings in stock, main dimensions to DIN 625-1, lip seals on both sides.
