FAG 23240-BE-XL Spherical roller bearings
Also known as : 23240-BE-XL, 23240E, 23240EAE4
- Inside Diameter: 200 mm
- Outside Diameter: 360 mm
- Width: 128 mm
- Basic dynamic load rating: 1940 kN
- Basic static load rating: 2700 kN
FAG 23240-BE-XL Bearing
FAG 23240-BE-XL Bearing details
| model | 23240-BE-XL |
|---|---|
| d | 200 mm |
| D | 360 mm |
| B | 128 mm |
| D1 | 305.3 mm |
| Da max | 343 mm |
| d2 | 235 mm |
| da min | 217 mm |
| ra max | 3 mm |
| rmin | 4 mm |
| Cr | 1940000 N |
| C0r | 2700000 N |
| Limiting speed | 1870 1/min |
| Reference speed | 1000 1/min |
| Cur | 219000 N Fatigue limit load, radial |
| e | 0.35 |
| Y1 | 1.95 |
| Y2 | 2.9 |
| Y0 | 1.91 |
| mass | 59 kg |
FAG 23240-BE-XL roller bearings, spherical roller bearing, Increased capacity design, main dimensions to DIN 635-2.
